Products  --  KVM Consoles - AK-Series

AK-1701-DVI
• 17“ LCD Monitor with LED Backlight
• Easy installation
• Low installation depth 411mm !!


AK-1701-DVI is a 17“ Monitor-Keyboard-Drawer with LED Backlight. A value keyboard with number block and touchpad completes the external design and makes it an allrouder device. The casing conforms the 1U Standard, is easily installed and mountable with the included mounting kit.

Specifications:
• Practical DB-37 Combo connector, combined with our included cable DLS-D01-1 (1 x DVI, 1 x USB and 2 x PS/2)
• compatible with the most PS/2-KVM and USB KVM-switches
• Support friendly external power supply
• Supports all USB suitable operating systems: for example DOS, Windows Series / Server 2008 / Server 2013, Linux, MacOS, etc.
• Permanent Keyboard /Mouse emulation for safe function on all computers and operating systems

Properties:
• 1U 17“ LCD console, 422mm total depth • Stepless, adjustable angle from 0 to 105° with high quality torque hinges • Easy one-man-assembly with the included installation angles • Adjustable depth: 411mm to 650mm (Standard) Optional: conversion kit for 560mm to 900mm • Chromed, hinged metal handle • Practical knurled screws • High graphic resolution, up to 1280 x 1024 with 60Hz

Keyboard Variants:
Available in following versions: German (DE), US-English (US), French (FR), Spanish (SP), Italian (IT). Swiss / German (CH) and swedish / finnish (SWE/FI)

Versions available on request: UK-English (UK), Turkish (TK), Russian(RU) and Arabian (AR). .
